The Terex® FM Ultra Fines™ plays a vital role in the effective management and recovery of ultra-fine sand from wastewater generated by washing processes.

This recovery unit can handle up to 450m³ per hour of slurry and is capable of capturing particles as small as 40 microns. By doing so, it significantly reduces the volume of solids that need to be managed in storage ponds or water treatment facilities.

Key Features

• Large volume conical tank with bolt on sides
• Removable chassis cover panels for improved serviceability
• Accessible lined pump and motor
• Cyclone array with easy access catch boxes
• Standard 8×4 Dewatering screen
• Fully galvanized, reversible walkways
• 3 Pump options available, dependent on application
